OMRON SYSDRIVE 3G3MX2

🔧 Omron SYSDRIVE 3G3MX2 – Technical Overview

The 3G3MX2 series is a compact, high-performance frequency inverter designed for a wide range of industrial applications.

⚙️ Control Methods

• Sensorless Vector Control (Open Loop Vector)
• V/f Control (Voltage/Frequency)

⚡ Power Range

• From 0.4 kW to 7.5 kW, depending on model

🔌 Power Supply

• Available in 230 V (1-phase or 3-phase) and 400 V (3-phase) models

🌀 Output Frequency

• Up to 590 Hz

🌟 Key Features

• Control of Permanent Magnet (PM) motors
• Positioning input via 90° phase difference pulse (up to 32 kHz)
• Single-phase pulse input (up to 32 kHz)
• Built-in safety functions:
• Safe Torque Off (STO)
• Complies with EN ISO 13849-1 Cat.3 PLe and IEC 61800-5-2
• EtherCAT® communication option
• Dual-channel safety inputs and EDM output

🛠️ Typical Applications

The 3G3MX2 inverter is ideal for use in:

• CNC machinery
• Packaging equipment
• Textile machines
• Printing systems
• Industrial robots
• Food and beverage production lines
